ANGEL-5S Oxygenerator 5Lpm

Location :  Home  >   Products  >  Health Oxygen Concentrator
ANGEL-5S Oxygenerator 5Lpm
Category : Health Oxygen Concentrator
Brief :

Special Features only provided by AngelBiss Technology

The world’s NO. 1 Oxygen Output Purity Fluctuation rate controlled within 0.1%.

Automatic heavy humidity remove molecular sieve

Independent Oxygen outlet & nebulizer outlet system

Child Lock settings

3 years warranty or 18000hours lifetime

Durable use for environment areas at high temperature (45℃), high altitude (4500m).




  • Description
  • Inquiry

5L Oxygen Concentrator

ANGELBISS, The first one to focus on Fluctuation of an oxygen concentrator, the first one CAN control the Fluctuation rate within 0.1%


ANGEL-5S
is the third generation of the AngelBiss small oxygen series which more exellent performance on sieve tank, master board sim and long services in high temperature&sea level areas.

FEATURES

A Touch operate multi-functional units.

5Liter with 93%±3% oxygen purity output for COPD users

Oxygen Purity Display by Numbers ( Accuracy 00.0%)

Timer

Large 6’ LED Light Display all functional data

Accumulated total running hours

Model and Functions

Model No Max O2 Flow PO2 urity Volts Watts O2 Pressure Noise Nebulizer Timer Alarm O2% Display

ANGEL-5S 5L/min 93%±3% AC 220V/115V 350W 70kPa 43 dB(A) YES YES YES YES

ANGEL-5A 5L/min 93%±3% AC 220V/115V 350W 70kPa 43 dB(A) NO YES YES YES

ANGEL-5N 5L/min 93%±3% AC 220V/115V 350W 70kPa 43 dB(A) YES YES NO NO

ANGEL-5 5L/min 93%±3% AC 220V/115V 350W 70kPa 43 dB(A) NO YES NO NO


Critical advantages are consists by below unique systems. AngelBiss holds all technologies to reserve the functionalities.

System Map Functions Parameters
Oxygen Generating System Oxygen Flow 0.5~5L/min
Oxygen Concentration 93% +3%
Oxygen Output Pressure 0.04-0.07Mpa
Oxygen Number Display YES

Nebulizer System Nebulize Mode YES
Individual Nebulizer Outlet YES
Display Method On LED screen
Operating Way By touch panel button
Accessories Nebulize nozzle and mask
Nebulizing Particle Size 3.6μm±25%

Screen Display System Display Material All by LED lights
What Can Be Displayed ? "Oxygen" light on
"Nebulize" light on
"Oxygen Percentage" light on
"Each Runing Time" light on
"Accumulated Time" light on
"Timer Setting Number"

Operating System Operating Panel SmartTouch
OXYGEN Start to produce Oxygen
NEBULIZE Start to run Nebulizer
TIMER "+" and "-" Seting from 0 to 3 hours
(15mins increase or decrease)

Safety System Low Oxygen Alarm Yes
Oxygen Pressure Protection Alarm Yes
Pressure Faulty Alarm Yes
Power off Alarm Yes
Compressor Faulty Alarm Yes
Overheated Protection Yes

Electrical System Power Consumption 420 W
Auto Power off by timer YES
Screen Sleep Mode YES
Noise Level <47dB(A)

Packing Machine Body Size 380x270x580mm
Package Size 440x340x650mm
Net Weight 16.5kg
Gross Weight 18.7kg
Body Material ABS, Glaze

Optional Functions Remote Control Optional
Voice Guide System Optional
