Multiple oxygen flow and high-pressure
options for different purposes. Especially made for fields with little or no
access to medical oxygen, or for a back-up supply in operation theaters,
industrial, acqua, diving etc. AngelBiss holds all self-developed technology on
high pressure oxygen generators which can supply over 90% oxygen at a pressure
from 2 bar to 6 bar.
1- Total 60LPM output
2- 1bar to 6 bar pressure adjustable
3- 93%±3% oxygen purity output
4 – Smaller storage square
Technical Specifications
|
Product Model |
LINER-60SP |
|
Max. oxygen flow |
60LPM |
|
Oxygen Concentration |
90% ~ 96% |
|
Pressure adjustment range |
0.14~0.6 Mpa(20.3~87psi) |
|
Noise |
≤55dB(A) |
|
Volts |
AC 220V/110V ± 10%, 50/60 ± 1Hz |
|
4650W, or depends |
|
|
Alarm |
Yes |
|
Work mode |
Continuous |
|
Net Weight |
240kg |
|
Gross Weight |
265kg |
|
Product Size |
1290x725x1215mm |
|
Package Size |
1380*810*1400mm |
Reference application
1 – For diving
2- For aqua
3- For industrial
4- For your DIY options
Note: This product can not attach to ventilators and anesthesia machines.
