Oxygen Concentration

90%-96%

90%-96%

Pulse Dose Equivalent Oxygen Output

Level 1=200mL/min

Level 2=400mL/min

Level 3=600mL/min

Level 4=800mL/min

Level 5=1000mL/min

Level 1=210mL/min

Level 2=400mL/min

Level 3=600mL/min

Level 4=800mL/min

Level 5=1000mL/min

Level 6=1100mL/min

Level 7=1120mL/min

Effective Respiratory Rate

10~40 breaths per minute

10~40 breaths per minute

Breath Trigger Sensitivity

≤0.2cmH₂O

≤0.2cmH₂O

Max. Output Pressure

150kPa

150kPa

Power Supply

AC 100~240V, 50~60Hz

DC 12-28V

AC 100~240V, 50~60Hz

DC 12-28V

Battery Info

Standard 14.4V

Capacity 8-cell 6600mAh, equivalent to 94.72Wh

Capacity 16-cell 13200mAh, equivalent to 94.72Wh+94.72Wh

Standard 14.4V

Capacity 8-cell 6600mAh, equivalent to 94.72Wh

Capacity 16-cell 13200mAh, equivalent to 94.72Wh+94.72Wh

Battery Runtime

8-cell: 1.5 hrs at Level 5

8-cell: 3.5 hrs at Level 1

16-cell: 3.5 hrs at Level 5

16-cell: 7 hrs at Level 1

8-cell: 1.5 hrs at Level 5

8-cell: 3.5 hrs at Level 1

16-cell: 3 hrs at Level 7

16-cell: 7 hrs at Level 1

Charging Time

8 hrs when charging on unit

4 hrs when charging with external charger

8 hrs when charging on unit

4 hrs when charging with external charger

Max. Power Consumption

70VA at Level 5

85VA at Level 7

Screen Size

2.8" TFT

2.8" TFT

Noise Level

≤45dB(A)

≤45dB(A)

Net Weight

2.28kg with 8-cell battery

2.68kg with 16-cell battery

2.28kg with 8-cell battery

2.68kg with 16-cell battery

Product Dimensions

187mm*88mm*237mm

187mm*88mm*237mm

Original Power Cord (Dual Type-C)

1 pc

Power Adapter 1 pc

Car Adapter

1 pc

Primary Filter Cotton

2 pcs

Secondary Filter Cotton 1 pc

Felt Cloth 1 pc

Backpack

1 pc

Nasal Cannula

1 pc

User Manual

1 pc
