Reference application
1- For hospital
2- For aqua, nano bubble, diving
3- For healthcare clinics
4- For your DIY options
Technical Specifications
Product Model | ANGEL-60HPT | ANGEL-80HPT | ANGEL-130HPT |
Max. oxygen flow | 60LPM | 80LPM | 130LPM |
Oxygen Concentration | 90% ~ 96% | ||
Pressure adjustment range | 0.14~0.5 Mpa(20.3~72.5psi) | ||
Max Auto Cut Off Pressure | 0.7 Mpa (101psi) | ||
Min Auto Cut On Pressure | 0.5 Mpa (72.5psi), customized available | ||
Buffer tank compacity | 600L | ||
Noise | ≤65dB(A) | ||
Volts | AC 380 V | ||
Power | 6650W, or depends | depends | depends |
Alarm | Yes | ||
Work mode | Intermittent by auto control | ||
Net Weight | 242kg | depends | depends |
Gross Weight | 269kg | depends | depends |
Product Size | 1290x730x1200mm | depends | depends |
Package Size | 1330*780*1380mm | depends | depends |
